3.5-inch TFT HMI Display Module with 800 x 480 Pixels Resolution and Capacitive Touch for Industrial Automation

Name: 3.5-inch TFT HMI Display Module with 800 x 480 Pixels Resolution and Capacitive Touch for Industrial Automation
Brand: Shenzhen Jingcai Intelligent Co., Ltd.
SKU: JC1060Q370C_I
Price: 114.00 USD
Availability: InStock

Model Number:	JC1060Q370C_I
Payment Terms:	L/C,T/T
Supply Ability:	5000PCS/day

Detail Information

Product Description

Detail Information

Flash:

16MB

Type:

TFT

Touch:

Capacitive Touch

Product Weight:

About 50g

Size:

3.5inch

Operating Temperature:

-20℃~70℃

Operatingtemperature:

-20°C To 70°C

Dimensions:

190 Mm X 130 Mm X 40 Mm

Highlight:

3.5-inch TFT HMI Display Module

800 x 480 Pixels Resolution HMI Touch Screen Monitor

Capacitive Touch Embedded Control Display Panel

Product Description

HMI Display Module Overview

The 190mm x 130mm x 40mm HMI Display Module is a high-performance 3.5-inch TFT screen engineered for industrial automation panels. Featuring 16MB flash memory and 800 x 480 pixel resolution, this compact module delivers exceptional clarity and reliability for demanding embedded applications.

Key Features

Product Name: HMI Display Module
Type: Human Machine Interface Display
Application: Industrial Automation Display Module
Use Case: Industrial Control Panel Screen
Storage Temperature: -30°C to 80°C
Operating Temperature: -20°C to 70°C
Product Weight: Approximately 50g
Display Size: 3.5 inch TFT

Technical Specifications

Parameter	Specification
Type	TFT
Resolution	800 x 480 Pixels
Brightness	300 Cd/m²
Touch Interface	Capacitive Touch
Operating Temperature	-20°C to 70°C
Storage Temperature	-30°C to 80°C
Product Weight	Approximately 50g
External Dimensions	107.5 mm (L) × 50 mm (W) × 3.45 mm (H)
Overall Dimensions	190 mm × 130 mm × 40 mm

Industrial Applications

The JC1060Q370C_I HMI Display Module serves as a versatile Machine Control Display Panel across multiple industries. Its 300 Cd/m² brightness ensures optimal visibility in various lighting conditions, while the robust temperature tolerance makes it suitable for harsh environments including outdoor installations and industrial sites.

Typical applications include factory automation panels, CNC machine interfaces, HVAC control systems, agricultural equipment displays, smart building control panels, and transportation systems where responsive and reliable user interfaces are critical.

Customization Options

Our HMI Display Module (Model JC1060Q370C_I) offers comprehensive customization services to meet specific project requirements. With a production capacity of 5000 units per day and 28-day delivery timeline, we support flexible payment terms including L/C and T/T to accommodate your procurement needs.

Production & Delivery

Supply Capacity: 5,000 pieces per day

Delivery Time: 28 days

Payment Terms: L/C, T/T

Technical Support & Services

Comprehensive technical support includes installation guidance, troubleshooting, firmware updates, and maintenance assistance. Detailed documentation and user manuals are provided, with regular software updates to enhance functionality and security throughout the product lifecycle.

Packaging & Shipping

Each HMI Display Module is securely packaged in anti-static bags with custom foam inserts, enclosed in sturdy cardboard boxes with clear labeling. We utilize reliable courier services with tracking options and ensure compliance with international export regulations for smooth customs clearance.

Frequently Asked Questions

Q: What is the model number of the HMI Display Module?

A: The model number is JC1060Q370C_I.

Q: What is the typical delivery time for this product?

A: Standard delivery time is 28 days.

Q: What payment terms are accepted?

A: We accept L/C (Letter of Credit) and T/T (Telegraphic Transfer).

Q: What is the production capacity for this model?

A: Production capacity is 5,000 pieces per day.

Q: Can you provide interface compatibility details?

A: The module features standard communication interfaces compatible with various industrial control systems. Please refer to the product datasheet or contact technical support for specific compatibility information.
